Home > STONE CRUSHERS > Inter-Row Series
Adjustable Working Widths
(70-110HP) >

Inter-Row 1000 Rock & Stone Crusher:
18" Working Width/Head
6" Working Depth
70-110HP Tractors
Valentini Inter-Row 1000 Stone & Rock Crusher

Alternative Views:


Availability:: Availability Varies From Season To Season
Product Code: INTER-ROW-CRUSHER


GENERAL FEATURES: SPECIFICATIONS:


  • Crusher's 'Diminishing Chamber' is Comprised of the Following:
    • Front Shear Bar Provides First Mechanical Contact for Reducing Fragments.
    • Rear Hardox Grid Provides Secondary Contact for Further Fragmentary Reduction.
    • Hydraulically Controlled Rear Containment Door Controls the Duration That Fragments Remain in the Chamber:
      • Rear Containment Door Can Be Opened or Closed On-The-Fly During Operation!
      • Containment Door Constructed for Extreme Service Duty & Wear Resistance.
    • Crusher Body Internal Hardox Lining is Replaceable.
  • Extreme Service Duty Rotor is Shock & Wear Resistant.
  • 19" Rotor Working Diameter, Tip to Tip.
  • Side Gear Drives are in Oil Bath Gearboxes.
  • Unique & Patented Labyrinth Seals Ensure Bearings are Protected from Dirt!
  • Wear Plates/Skid Shoes on Both Sides of Crusher.
  • Crusher Includes Shear Bolt Protected 540RPM PTO Shaft.
  • Sample Images Show Tractor For Reference Only - Tractor is Not Included.
    • Sample Video is of an L1500 For Reference Only.
